Tubular Feeder (GS-SAT2203) [Single Track]

Brand Name : GS

Model Number : GS-SAT2203

Place of Origin : China

MOQ : 1/PCS

Price : USD+negotiable+pcs

Payment Terms : T/T

Supply Ability : 1+pcs+per days

Delivery Time : 1-3 days

Packaging Details : 1650*100*560mm

Model : GS-SAT2203

Overall dimensions (length * width * height) : 1560*75*450mm

Weight : 18KG

Working voltage : DC 24V

Gas source requirements : 0.5-0.7Mpa

Maximum current : 2A

Feeding speed : ＜2s/Pcs

Operation panel : 0.96-inch TFT color screen, 80*160 pixels

Pipe replacement time : ≤10S

Channel : Single-channel/dual-channel( Default single channel)

Pin bending function : Optional separately(Default none)

Plastic surgery function : Optional separately(Default none)

Lifting function : Optional separately(Default none)

Foot cutting function : Optional separately(Default none)

Adapt to the length of the material pipe : 400-600mm

Adapt to the height of the material pipe : 10mm-45mm

Adapt to the width of the material pipe : 10mm-40mm

Condition : New
